Torque

Category:

Specifications



AVAILABLE SIZES



SIZE BOLT PATTERN OFFSET
15 x 6.5 4 x 100 e+18/ e+35 to +40
15 x 6.5 4 x 108 e+18/ e+35 to +40
15 x 6.5 4 x 110 e+18/ e+35 to +40
15 x 6.5 4 x 114.3 e+18/ e+35 to +40
15 x 6.5 5 x 100 e+35 to +40
15 x 6.5 5 x 108 e+35 to +40
15 x 6.5 5 x 110 e+35 to +40
15 x 6.5 5 x 112 e+35 to +40
15 x 6.5 5 x 114.3 e+35 to +40
15 x 6.5 5 x 120 e+35 to +40
16 x 7 4 x 100 e+27 to +45
16 x 7 4 x 108 e+27 to +45
16 x 7 4 x 110 e+27 to +45
16 x 7 4 x 114.3 e+27 to +45
16 x 7 5 x 100 e+27 to +45
16 x 7 5 x 108 e+27 to +45
16 x 7 5 x 110 e+27 to +45
16 x 7 5 x 112 e+27 to +45
16 x 7 5 x 114.3 e+27 to +45
16 x 7 5 x 120 e+27 to +45
17 x 7.5 4 x 100 e+7/ e+25 to +48
17 x 7.5 4 x 108 e+7/ e+25 to +48
17 x 7.5 4 x 110 e+7/ e+25 to +48
17 x 7.5 4 x 114.3 e+7/ e+25 to +48
17 x 7.5 5 x 100 e+45 to +48
17 x 7.5 5 x 108 e+45 to +48
17 x 7.5 5 x 110 e+45 to +48
17 x 7.5 5 x 112 e+45 to +48
17 x 7.5 5 x 114.3 e+45 to +48
17 x 7.5 5 x 120 e+45 to +48
17 x 8 4 x 100 e+20 to +35/ e+45 to +48
17 x 8 4 x 108 e+20 to +35/ e+45 to +48
17 x 8 4 x 110 e+20 to +35/ e+45 to +48
17 x 8 4 x 114.3 e+20 to +35/ e+45 to +48
17 x 8 5 x 100 e+30 to +35/ e++48
17 x 8 5 x 108 e+30 to +35/ e++48
17 x 8 5 x 110 e+30 to +35/ e++48
17 x 8 5 x 112 e+30 to +35/ e++48
17 x 8 5 x 114.3 e+30 to +35/ e++48
17 x 8 5 x 120 e+30 to +35/ e++48
17 x 9 4 x 100 e+10 to +18/ e+30 to +35
17 x 9 4 x 108 e+10 to +18/ e+30 to +35
17 x 9 4 x 110 e+10 to +18/ e+30 to +35
17 x 9 4 x 114.3 e+10 to +18/ e+30 to +35
17 x 9 5 x 100 e+10 to +18/ e+25 to +35
17 x 9 5 x 108 e+10 to +18/ e+25 to +35
17 x 9 5 x 110 e+10 to +18/ e+25 to +35
17 x 9 5 x 112 e+10 to +18/ e+25 to +35
17 x 9 5 x 114.3 e+10 to +18/ e+25 to +35
17 x 9 5 x 120 e+10 to +18/ e+25 to +35
17 x 9.5 4 x 100 e+12 to +20/ e+35 to +40
17 x 9.5 4 x 108 e+12 to +20/ e+35 to +40
17 x 9.5 4 x 110 e+12 to +20/ e+35 to +40
17 x 9.5 4 x 114.3 e+12 to +20/ e+35 to +40
17 x 9.5 5 x 100 e+12 to +20/ e+30 to +40
17 x 9.5 5 x 108 e+12 to +20/ e+30 to +40
17 x 9.5 5 x 110 e+12 to +20/ e+30 to +40
17 x 9.5 5 x 112 e+12 to +20/ e+30 to +40
17 x 9.5 5 x 114.3 e+12 to +20/ e+30 to +40
17 x 9.5 5 x 120 e+12 to +20/ e+30 to +40
18 x 7.5 4 x 100 e+25/ e+30 to +38/ e+40 to +48
18 x 7.5 4 x 108 e+25/ e+30 to +38/ e+40 to +48
18 x 7.5 4 x 110 e+25/ e+30 to +38/ e+40 to +48
18 x 7.5 4 x 114.3 e+25/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 100 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 108 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 110 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 112 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 114.3 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 5 x 120 e+10/ e+30 to +38/ e+40 to +48
18 x 7.5 8H e+37 to +42
18 x 8 4 x 100 e+25/ e+35 to +44/ e+45 to +50
18 x 8 4 x 108 e+25/ e+35 to +44/ e+45 to +50
18 x 8 4 x 110 e+25/ e+35 to +44/ e+45 to +50
18 x 8 4 x 114.3 e+25/ e+35 to +44/ e+45 to +50
18 x 8 5 x 100 e+10/ e+35 to +44/ e+45 to +50
18 x 8 5 x 108 e+10/ e+35 to +44/ e+45 to +50
18 x 8 5 x 110 e+10/ e+35 to +44/ e+45 to +50
18 x 8 5 x 112 e+10/ e+35 to +44/ e+45 to +50
18 x 8 5 x 114.3 e+10/ e+35 to +44/ e+45 to +50
18 x 8 5 x 120 e+10/ e+35 to +44/ e+45 to +50
18 x 8 8H e+40 to +48
18 x 8.5 4 x 100 e+25 to +35/ e+45 to +48
18 x 8.5 4 x 108 e+25 to +35/ e+45 to +48
18 x 8.5 4 x 110 e+25 to +35/ e+45 to +48
18 x 8.5 4 x 114.3 e+25 to +35/ e+45 to +48
18 x 8.5 5 x 100 e+25 to +44/ e+45 to +48
18 x 8.5 5 x 108 e+25 to +44/ e+45 to +48
18 x 8.5 5 x 110 e+25 to +44/ e+45 to +48
18 x 8.5 5 x 112 e+25 to +44/ e+45 to +48
18 x 8.5 5 x 114.3 e+25 to +44/ e+45 to +48
18 x 8.5 5 x 120 e+25 to +44/ e+45 to +48
18 x 8.5 6H e+42
18 x 9 4 x 100 e+20 to +30
18 x 9 4 x 108 e+20 to +30
18 x 9 4 x 110 e+20 to +30
18 x 9 4 x 114.3 e+20 to +30
18 x 9 5 x 100 e+5 to +10/ e+12 tO +30
18 x 9 5 x 108 e+5 to +10/ e+12 tO +30
18 x 9 5 x 110 e+5 to +10/ e+12 tO +30
18 x 9 5 x 112 e+5 to +10/ e+12 tO +30
18 x 9 5 x 114.3 e+5 to +10/ e+12 tO +30
18 x 9 5 x 120 e+5 to +10/ e+12 tO +30
18 x 9.5 4 x 100 e+25 to +35
18 x 9.5 4 x 108 e+25 to +35
18 x 9.5 4 x 110 e+25 to +35
18 x 9.5 4 x 114.3 e+25 to +35
18 x 9.5 5 x 100 e+10 to +15/ e+18 to +35
18 x 9.5 5 x 108 e+10 to +15/ e+18 to +35
18 x 9.5 5 x 110 e+10 to +15/ e+18 to +35
18 x 9.5 5 x 112 e+10 to +15/ e+18 to +35
18 x 9.5 5 x 114.3 e+10 to +15/ e+18 to +35
18 x 9.5 5 x 120 e+10 to +15/ e+18 to +35
